Double Layer Trapezoidal Roof Sheet Roll Forming Machine
The Double Layer Trapezoidal Roof Sheet Roll Forming Machine is essentially a device that ingeniously integrates two independent trapezoidal tile pressing systems into one. It can produce two different specifications or wave heights of trapezoidal roof panels using a single set of control systems on one machine, making it a highly popular piece of equipment in the field of steel structure construction. The core concept of this type of equipment is the "two-in-one" design philosophy. The upper and lower layers consist of two independent roller systems, sharing the same power, cutting, and control systems. During production, by simply switching the feed channel, operators can flexibly choose which tile type to produce without the need for equipment replacement.
Main application scenarios：
The trapezoidal tiles produced by this equipment are widely used in various industrial and civil construction fields due to their unique structural strength
• Industrial plants:
Roof and wall systems for various steel structure plants, warehouses, and workshops. The drainage performance and wind resistance of trapezoidal tiles can well meet the needs of such large-span buildings.
• Logistics warehousing center:
This type of building has high requirements for construction period and cost. The double-layer forming machine can quickly and economically produce the required panels on site or nearby, meeting the construction needs of large-scale warehousing projects.
• Commercial and public buildings:
such as large supermarkets, sports venues, convention centers, airport terminals, etc. These buildings have large volumes and require a wide variety and large quantity of metal roof panels, which can be well handled by double-layer equipment.
• Civilian and temporary buildings:
In the renovation of roofs and walls of some rural self built houses, prefabricated houses, and container houses, this cost-effective trapezoidal tile is also widely popular.
Product Attributes :
|
1.Formed Material
|
PPGI,GI,AI,GL
|
Thickness:0.3-0.8mm
Width:1220mm(As per profile drawing)
|
||
|
2.Decoiler
|
Hydraulic automatic decoiler
|
Manual decoiler(will give you as free）
|
||
|
3.Main body
|
Roller station
|
16+18 rows(As your requirement)
|
||
|
Diameter of shaft
|
80mm solid shaft
|
|||
|
Material of rollers
|
45# steel, hard chrome plated on the surface
|
|||
|
Machine body frame
|
350 H steel
|
|||
|
Drive
|
As your requirement
|
|||
|
Dimension(L*W*H)
|
customize
|
|||
|
Weight
|
8.5T
|
|||
|
4.Cutter
|
Automatic
|
cr12mov material, no scratches, no deformation
|
||
|
5.Power
|
Motor Power
|
5.5KW
|
||
|
Hydraulic system power
|
5.5KW
|
|||
|
6.Voltage
|
380V 50Hz 3Phase
|
As your requirement
|
||
|
7.Control system
|
Electric Box
|
Customized(famous brand)
|
||
|
Language
|
English(Support multiple languages)
|
|||
|
PLC
|
Automatic production of the whole machine. Can set batch, length, quantity, etc.
|
|||
|
18.Forming Speed
|
15-20m/min
|
The speed depends on the shape of the tile and the thickness of the material.
|
||
Core features and advantages：
The popularity of this device is mainly due to several practical advantages:
1. Saving investment, dual-use:
This is its core value. For construction sites or processing plants that require multiple types of roof panels, buying one equipment is equivalent to buying two before, greatly reducing the initial equipment investment cost.
2. Save space and compact layout:
Traditional two devices require a very large installation space. The double-layer machine, with its three-dimensional layout, occupies a much smaller area and is particularly friendly to customers with limited factory space.
3. Flexible production and fast switching:
Simply feed the steel coil into the upper or lower feeding port, and the product model can be switched within a few minutes, greatly improving the response speed to different orders.
4. Durable and reliable, with guaranteed accuracy:
Although the price is advantageous, the key components are not ambiguous. The body is mostly welded with H-shaped steel, the spindle is made of 45 # steel, and the drum is chrome plated, which ensures that the equipment can operate stably for a long time, and the produced sheet metal has precise dimensions and beautiful appearance.
5. Easy to operate and highly automated:
Equipped with a PLC control system and touch screen, workers can easily get started after simple training. It can achieve automatic length setting, automatic counting, and automatic cutting, greatly reducing the difficulty and error rate of manual operation.
